Steel Truck Wheels

Steel truck wheels designed for usa market
Usage on drive, steer and trailer axle
Positive hub-piloting and cone-lock clamping leads to improved wheel life

Send Inquiry

Description

Introduction

The Steel Truck Wheels are significantly stronger than others. Our products require more force, and it's almost impossible to break them. Given their usual utilitarian appearance, pure cosmetic damage is generally not a big problem. Finally, our products are cheap and high-quality, which is deeply loved by our customers.

Feature

Due to the nature of the raw materials used in Steel Truck Wheels, our product has an incredible weight. Secondly, its lighter weight has an impact on the handling of the vehicle, especially when it comes to steering precision, mileage and acceleration ability, and is more responsive. Lastly, our product is quieter and provides you with a great driving experience.

Specifications：

22.5x8.25
NO.	bolt hole	bolt dia	PCD	Center hole	rim (mm)	disc(mm)	bolt hole type	offset	weight	tyre
1	8	φ32	φ275	φ214	7	14	SR22	168	45.6	11R22.5, 275/60R22.5, 275/70R22.5, 275/80R22.5
15	8	φ32	φ285	φ221	8	16	SR22	169
16	10	φ26	φ285.75	φ220	8	16	straight	169	51.7
17	10	φ32	φ285.75	φ222	8	16	SR22	169	51.1
18	10	φ26	φ335	φ281	8	16	straight	169	50.8
19	10	φ27	φ335	φ281	8	16	SR18	169	50.7
20	10	φ26	φ285.75	φ220	6	11	straight	168	36.2

24.5x8.25
NO.	bolt hole	bolt dia	PCD	Center hole	rim (mm)	disc(mm)	bolt hole type	offset	weight	tyre
21	10	φ26	φ335	φ281	7	14	straight	168	50.2	11R24.5,285/75R24.5
23	10	φ32	φ285.75	φ222	6	11	SR22	168		11R24.5,285/75R24.5
