Truck Tyre

222 truck tyre is specially designed in driving wheels of concrete mixed truck.
The horizontal pattern groove and tire shoulder block pattern design,
with excellent grasp performance and braking performance.

Send Inquiry

Description

Product Information

The truck tyre is specially designed for the driving wheel of concrete mixer truck. Its horizontal grooves and tread pattern design of tire shoulder block have excellent grasping and braking performance. The tyre also adopts a unique tread groove, which can improve the self-cleaning performance of the tyre.

Features

The truck tyre is equipped with a rubber like composition, which prevents the rubber of the air tight layer from penetrating into the part between the carcass cord fabric. Its air tight layer can ensure to maintain the inflation pressure of the tire and wrap the inner part of the tire. The bead of the tire is the strongest in the tire structure, and can be sealed with the rim to support the vehicle.

Specifications:

Size	Ply	Standard	Load	Speed	Air Pressure		Dual Load		Single Load		Overall	Section	Tread
Size	Ply	rim (inch)	Index	Rating	Kpa	PSI	Kg	LBS	Kg	LBS	Diameter(mm)	Width (mm)	Depth (mm)
11R22.5	16	8.25	148/146	M	850	123	2900	6393	3150	6945	1050	279	21
12R22.5	18	9.00	152/149	M	930	135	3250	7165	3550	7826	1085	300	21
13R22.5	18	9.75	156/150	L	875	127	3350	7385	4000	8818	1124	320	21
315/70R22.5	18	9.00	154/150	M	900	131	3350	7385	3750	8267	1014	312	14
295/80R22.5	16	9.00	152/148	M	850	123	3150	6945	3550	7826	1044	298	15
315/80R22.5	18	9.00	156/150	L	850	123	3350	7385	4000	8818	1076	312	15
